Keyboard Config and MIDI Channel Config

User Manual Danhild VARIO - Version 1

4.9.7 Keyboard Config

The Keyboard Config function sets the operation of the keys.

1. Press the MENU button.

2. Use the - and + buttons to select the

Keyboard Config function on the display.

3. Press the ENTER button. The display shows

the current setting of one of the manuals.

4. Use the - and + buttons to select the manual

the setting of which must be changed.

5. Press the ENTER button. The cursor moves

to the second line of the display.

6. Use the - and + buttons to select a setting for the operation of the keys.

Automatic:

The manual has been set to High. When activating a programmable

MIDI register, the manual will be set to Velocity automatically.

High:

The keys respond when touched very lightly.

Low:

The keys respond when pressed further.

Velocity:

The keys are touch-sensitive.

7. Press the ENTER button. The keyboard

setting is now saved in the memory and

the cursor moves back to the first line of

the display.

8. Press the MENU button to return to the

main menu.

9. Press the MENU button to exit the menu.

Menu:

Keyboard Config

>Great

Automatic

>Great

Automatic

>Great

Automatic

Menu:

Keyboard Config

Mem: 1

Vol: 25

Tr: 0/440

Exp: Sw

4.9.8 MIDI channel Config

MIDI is a protocol for communication between the instrument and other devices, such

as PC, Sequencer or other musical instruments. MIDI means Music Instrument Digital Interface.

The programmable MIDI stops allow you to control any module voice through any

MIDI channel (1-16).

The four parts of the programmable MIDI code are: Channel, Msb, Lsb and Voice.

1. Press the MENU button.

2. Use the - and + buttons to select the MIDI

Config function on the display.

3. Press the ENTER button. A question to

select a MIDI stop to configure appears on

the display.

4. Activate the MIDI stop which has to be configured

(MIDI from the Swell, for example).

The display shows on the first line:

Swell Channel

(the selected MIDI stop and the first part of the

MIDI code) and on the second line the settings of

all four parts: Channel, Msb, Lsb and Voice.

Menu:

MIDI Config

Select a MIDI

Stop to config

Swell Channel

2 0 0 1
