7

User Manual Danhild VARIO - Version 1

3.2 Switch on

Switch on the instrument with the on/off switch at

the top of the instrument, next to the upper/lower button.

Wait some seconds.

Starting the control functions and the

settings will take some time.

The lamps of the standard set functions light up.

The settings appear in the display.

3.3 Light, music stand:

The light in the music stand is switched on and off with the

button to the left of the music stand.

3.4 Light, pedalboard:

The light for the pedal keyboard is switched on and off automatical-

ly with the organ. The light to the pedal board can not be switched

on and off separately; but will always be switched on and off

simultaneously with the instrument.

3.5 The up/down function, keyboards:

The keyboards can be raised/lowered

(infinitely adjusted in the height) using the large button

(with arrows on it) that is located furthest forward

on the top of the right side the instrument.

3.6 Transport and storage

Pay attention to the following during transport and storage:

1. Remove the music stand and the pedal keyboard from the organ.

2. Relative humidity within the storage area: 40 to 70 %.

3. Temperature: 10 to 40 Celcisus degrees.

3.7 The up/down function, organ bench:

The organ bench can be raised/lowered (infinitely adjusted in the

height) using the large button (with arrows on it) that is located to

the left on top of the bench.

Initializing…

Please wait

Mem: 1

Vol: 25

Tr: 0/440

Exp: Sw

In spite of the built-in security sensors, the power of the lifting mechanisms is

VERY strong !

THEREFORE:

Do NOT leave minors unattended while using the

height adjustment of either the Keyboards or the bench !

Always be very careful during any adjustment !

The manufacturer, distributors and dealers will therefore not

in any way become responsible for any personal accidents and injuries!
